5440, 5460, 5720, 5730, 5820, 5830 Upper & Rear Feed Roll Assembly

5200-5400-5440-5460-5720-5730-5820-5830-Upper-Feedroll-Assembly

Parts

Sch. ID Product Image Kooima # Title Replaces OEM # Price Quantity
1 K43635 Feed Roll, Upper Front (Kooima Stainless Steel) AE43635 $1,110.00
1a K00016WW Feed Roll, Upper Front AFH202052, AE43198 $590.80
2 K43635T Feed Roll Tooth for K43635 $36.85
2a K43635FT Flat Replaceable Tooth $35.35
2b K43635TBK Hardware Kit for K43635T & K43635FT $22.30
2c K00015WW Bolt-On Feed Roll Tooth for K00016WW $29.30
3 K43635S Sprocket $39.35
4 K72037 Shaft AE43198 $105.75
5 K9865 Bearing, Upper/Lower Front Feed Rolls JD9865 $10.00
6 K53699 Seal E53699 $4.00
